Bettersize Bettersizer 2600 Plus - BT-812 - BT-912 - PIC-1 01.20-07.11-07.12-09.06

Bettersizer 2600 Plus combines laser diffraction and dual-camera dynamic imaging on one modular platform, delivering size and shape characterisation across 0.02–3500 μm. Laser diffraction provides fast, repeatable particle size distributions(PSD) using a 92-detector array and Mie/Fraunhofer models. Dynamic imaging captures high-speed particle images to quantify size and shape, with visual evidence for agglomerates, irregular particles, and oversized tails. With a modular design, Bettersizer 2600 Plus supports a broad selection of wet and dry dispersion units. This enables flexible setups for different sample types, volumes, and solvents, so one instrument can meet diverse measurement needs.

Specifications:

Principle Laser diffraction technology, Dynamic image analysis
Analysis Mie scattering theory, Fraunhofer diffraction theory, Dynamic image analysis
Measuring range* 0.02 - 2,600 μm (wet); 0.1 - 2,600 μm (dry); 2 - 3,500 μm (dynamic image)
Accuracy* ≤ 0.5%
Repeatability* ≤ 0.5%
Number of size classes 100 (adjustable)
Measuring range 2 - 3,500 μm
